Design of Vacuum Sucker System Based on Side Channel Blower

2023-05-15 16:01
Vacuum sucker systems are used in various industrial and commercial applications where it is necessary to collect dust, debris, or other types of waste material from a specific area. In such systems, a vacuum source is required to generate suction that can pull the material from the surface into a collection container. Side channel blowers are often used as vacuum sources in such systems due to their high efficiency, reliability, and low maintenance requirements. In this article, we will discuss the design of a vacuum sucker system based on a side channel blower.
Design Considerations:
The design of a vacuum sucker system based on a side channel blower requires careful consideration of several factors, such as the required suction power, the size of the collection container, and the distance between the blower and the suction point. Additionally, the material being collected can also impact the design, as some materials may require specialized collection containers or additional filtration.
Suction Power:
The suction power required for a vacuum sucker system depends on the size and weight of the material being collected, as well as the surface area from which the material needs to be removed. The suction power is typically measured in cubic feet per minute (CFM) or air velocity in feet per minute (FPM). The side channel blower's suction power is determined by its flow rate, which is measured in cubic meters per hour (m³/h). The flow rate required for the vacuum sucker system can be calculated by multiplying the required CFM or FPM by the cross-sectional area of the suction point.
Distance between the Blower and Suction Point:
The distance between the blower and suction point is critical for maintaining the required suction power. Longer distances between the two will result in a decrease in suction power, and the system's overall efficiency will be reduced. This is particularly important when dealing with larger suction areas, as the distance will impact the flow rate and pressure required to maintain the required suction.

Filtration is an important consideration when designing a vacuum sucker system, particularly when collecting fine dust or other hazardous materials. Filters are typically used to prevent the material from entering the blower and causing damage, but they can also be used to capture the material before it enters the collection container. The type of filter used will depend on the material being collected and the system's specific requirements.
In conclusion, the design of a vacuum sucker system based on a side channel blower requires careful consideration of several factors, including suction power, collection container size, distance between the blower and suction point, and filtration requirements. Proper design and maintenance of the system will ensure efficient and reliable operation, and regular maintenance and cleaning will extend the system's lifespan. Overall, a properly designed and maintained vacuum sucker system can significantly improve industrial and commercial processes by reducing waste and increasing efficiency.
